Product Overview
The Evolution EVOMAG42 Magnetic Drill is versatile, accurate and fast, with strong magnetic adhesion (1500kg), the EVOMAG42 is an essential tool when performing heavy-duty industrial and steel fabrication work.
The cuts are precise and clean due to an optimised rotation speed (450rpm) and all popular broaching capacities are covered (12-42mm). and the innovative adjustable head system means twist drills can be used to full capacity.
Supplied with:
1 x 1/2in Chuck and Key
1 x Coolant Tank System
3 x Handles
1 x Chuck Adaptor
1 x Safety Strap
1 x Safety Guard
3 x Hex Keys
1 x Carry Case
6 x 25mm Annular Cutters: 12, 14, 16, 18, 20, 22mm
1 x Pilot Pin
1 x Magnetic Swarf and Chip Collector Wand
Specification:
Input Power: 1,200W.
No Load Speed: 450/min.
Magnet Adhesion: 1500kg.
Maximum Cutter Diameter: 42mm, Depth: 50mm.
Dimensions Rack Fully Raised (HxWxL): 580 x 320x 180mm, Lowered: 340 x 320 x 180mm.
Magnet Dimensions (HxWxL): 40 x 90 x 180mm.
Cutter Retainer Internal Diameter: 19mm Weldon Shank.
Recommended Maximum Duty Cycle: 30 minutes.
Sound Pressure Level LPA: 89.4 dB(A).
Weight: 10.9kg.
