Product Overview
- Self-adjusting cutting and stripping tool (No. 8146) for modern electrical installations and equipment circuitry (90 % of all wires can be stripped without any adjustment of the tool)
- The use of easily exchangeable module inserts allows accurate stripping of a wide range of insulation materials, including PVC and PTFE, with just one tool
- With flat blade
- Dimensions: 191 x 123 x 20 mm
- No. 8146-2 with circular blade: 4-16 mm²/AWG 10-5
- No. 8146-3 with V-blade: PTFE 0.1- 4 mm²/AWG 28-12 (for all insulations)
- Cutting values: Flexible conductors up to 10 mm²/AWG 8
- Rigid wires up to 1.5 mm² / AWG 16
Technical Specifications
| Net weight [kg] | 0.18 kg |
|---|---|
| Material | Plastic |
| Colour | black |
| Design non-sparking | No |
| Cable cross section [mm²] | 0.02-10 mm² |
| Wire gauge AWG | 34-8 |
