Product Overview
- Manually operated, with non-slip cross knurling
- Chromed
Technical Specifications
| Net weight [kg] | 0.083 kg |
|---|---|
| Total length [mm] | 55 mm |
| Material | Vanadium steel |
| Surface | chrome-plated |
| Standard | DIN 3120 - C 10, ISO 1174 |
| Drive mount, square [metric] | 10.0 mm |
| Drive connector square [inch] | 3/8" |
| Output tip reference standard | DIN ISO 2380-1 - Form B |
| Remuneration of the output tip | phosphated |
| Tip size Slot | 12.0 |
| Backup | Ball Catching Cricket |
| Tip length | 23.0 mm |
| Insert Ø Actuator | 20.5 mm |
| Blade thickness | 2.0 mm |
