Technical Specifications
| Net weight [kg] | 0.084 kg |
|---|---|
| Total length [mm] | 26 mm |
| Material | Steel |
| Surface | manganese-phosphated |
| Standard | DIN 3121 - G 12,5, ISO 1174 |
| Drive mount, square [metric] | 12.5 mm |
| Drive connector square [inch] | 1/2" |
| Screw size | M12 |
| Tip size TX (protrude) | TX 55 |
| Backup | Circlip and pin |
| Insertion depth 1 | 26.0 mm |
| Insert-Ø 1 | 25.0 mm |
| Actuation type | machine-operated |
