Technical Specifications
| Net weight [kg] | 0.776 kg |
|---|---|
| Total length [mm] | 66 mm |
| Material | Steel |
| Surface | blued |
| Standard | DIN 3121 - H 25, ISO 1174 |
| Drive mount, square [metric] | 25.0 mm |
| Drive connector square [inch] | 1" |
| Backup | Circlip and pin |
| Width across flats 1 [AF] | 1.1/2" |
| Working length | 66.0 mm |
| Insert-Ø 1 | 60.0 mm |
| Insert-Ø 2 | 54.0 mm |
| Operating depth | 22.0 mm |
| Actuation type | machine-operated |
