Technical Specifications
| Net weight [kg] | 0.045 kg |
|---|---|
| Total length [mm] | 30 mm |
| Material | Steel |
| Surface | blued |
| Width across flats 1 [mm] | 6 |
| Standard | not standardised |
| Drive mount, square [metric] | 10.0 mm |
| Drive connector square [inch] | 3/8" |
| Backup | Circlip and pin |
| Working length | 30.0 mm |
| Insert-Ø 1 | 11.0 mm |
| Insert-Ø 2 | 19.0 mm |
| Operating depth | 3.0 mm |
| Actuation type | machine-operated |
