Product Overview
Ideal for workshop or roadside use, this jack takes the effort out of lifting heavy plant, tractors and commercial vehicles. For extra safety, features dead man's handle and multi-position locking handle. Supplied with extensions that close the gap between the saddle of the jack and the jacking point. See table for detailed specification.
- HEAVY-DUTY HYDRAULICS - Powerful and reliable, ideal for workshop or roadside use.
- AIR OPERATED - Takes the effort out of lifting heavy plant, tractors and commercial vehicles.
- SAFETY LOCK - Dead man’s control and sectional pump handle for manual operation, when air is unavailable.
- JACKING POINT EXTENSIONS - Supplied with 20/60/100mm extensions to close the gap between the saddle of the jack and the jacking point.
- LOWERING SYSTEM - Automatic dual spring controlled.
- OVERLOAD SAFETY VALVE - Safety valve fitted to prevent damage to the unit.
Technical Specifications
| Air Consumption | 9.5cfm |
|---|---|
| Capacity | 50 Tonne |
| Chassis Length | 595mm |
| Extensions | 20/60/100mm |
| Maximum Height (inc. Extension)/Capacity-Stage 1 (mm/tonne) | 650/50mm |
| Maximum Height (inc. Extension)/Capacity-Stage 2 (mm/tonne) | 595mm |
| Maximum Height (inc. Extension)/Capacity-Stage 3 (mm/tonne) | 625mm |
| Minimum Saddle Height | 288mm |
| Nett Weight | 52.9kg |
| Piston Stroke | 155mm |
| Screw Extension | 107mm |
| Working Pressure | 109-123psi |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
