Product Overview
- Double sided usable hooks
- Especially suitable for separating and pulling off flush fitting parts
- Particularly economical due to the multiple adjustment possibilities of the clamping depth
Technical Specifications
| Usable clamping reach [mm] | 325 mm |
|---|---|
| Spindle thread size | G 1/2 x 350 |
| Width of hooked foot [mm] | 25 mm |
| Usable depth of hooked foot d2 [mm] | 14 mm |
| Thickness of hooked foot at tip | 3.5 mm |
| Width across flats [mm] | 22 mm |
| Tractive force (max.) [t] | 7.5 |
| Number of arms | 2 |
| Net weight [kg] | 4.6 kg |
| Can be retrofitted with hydraulic spindle | No |
| reversible hooks | Yes |
| Clamping width (max.) external pulling [mm] | 160 mm |
| Hydraulic spindle optional | 1.06/HSP1 |
