Product Overview
- Lay-on slip joint and toothed recess
- Clamps automatically on pipes and nuts
- Version C = Handles checkered
- Version JC = with 2-component handles
- No. 145 10 = 7-way adjustable, with extra narrow jaws
- No. 145 20= 11-way adjustable
Technical Specifications
| Net weight [kg] | 0.38 kg |
|---|---|
| Total length [mm] | 260 mm |
| Total width [mm] | 55 mm |
| Total height [mm] | 19 mm |
| Material | Chrome-vanadium steel |
| Width of head 1 [mm] | 47.0 mm |
| Surface | chrome-plated |
| Clamping width [mm] | 39 mm |
| Standard | DIN ISO 8976 - Form A |
| Handle design | dip-insulated |
| Handle colour | blue |
| Clamping width [inch] | 1 9/16" |
| Design non-sparking | No |
| Jaw length L3 [mm] | 41 mm |
| Joint types | applied joint |
| Head thickness [mm] T1 | 7.8 mm |
| Jaw shape [mm] | flat jaws |
| Width of centres W4 [mm] | 8.0 mm |
| Hardening process | Induction hardened |
