Product Overview
- Assortment: Ideally suited for service and maintenance work on agricultural machinery
- Tools in metric dimensions
- GEDORE Check-Tool-System: 2-colour foam insert to check that the set is complete
- Resistant against oils and grease
- In workbench no. 1504XL 1411
- Body: Sheet steel, corrosion and scratch-resistant, powder-coated
- 30 mm thick multiplex laminated beech wood board, surface additionally protected by linseed oil varnish
- Large storage space with lower shelf and door
- Safety through heel protection for persons
- Drawers: Central locking with cylinder clock
- 1 XL drawer (W 1055 x D 400 mm)
- 6 wide drawers (W 640 x D 400 mm) with full extension, removable
- Safety locking per drawer, one-hand operation
- Guide rails with ball bearings
- 2 GEDORE heavy-duty wheels with roller bearings (fixed castors
- 200 mm)
- 2 GEDORE easy-running wheels with ball bearings (swivel castors
- 125 mm), both with total brake each
- The GEDORE trapezoidal axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads
- Options: Expandable with rear panel no. R 1504 XL-L
- Special colors on request
Technical Specifications
| Contents (Qty of pieces) | 306 |
|---|---|
| Net weight [kg] | 174.68 kg |
| Total length [mm] | 1.250 mm |
| Total width [mm] | 630 mm |
| Total height [mm] | 985 mm |
| Material | Steel sheet |
| Parts list (Text) | Rolling workbench extra wide 1504 XL 1710 | 1.25 m, Screwdriver bit set 1/4" 620-024, Square handle 1/4" 2098, Socket 20 4 4.5 5 5.5 6 7 8 9 10 11 12 13 14 mm, Screwdriver bit 1/4" IN 20 4 5 6 8 mm, Screwdriver bit ITX 20 T8 T9 T10 T15 T20 T25, Rever |
| Colour | blue |
| RAL colour tone | RAL 5017 |
| Drawer type | 1x Type XL, H. = 75 mm extra wide, 7x Type 1b, H. = 67 mm, 1x Type 2b, H. = 137 mm |
| Number of drawers | 9 |
| Load capacity kg | 750 kg |
| Static load carrying capacity [kg] | 1000 kg |
| Load capacity per drawer [kg] | 40 kg |
| Load capacity heavy duty drawer [kg] | 60 kg |
