Product Overview
- Rings deep offset, strong but thin walls
- Satin non-glare finish
- Carefully forged and professionally machined: Ring: thin-walled
- 5° deep offset from shaft, with UD profile for gentle transmission of force
- High bending strength - does not fracture or splinter when overloaded, thus minimising the risk of injury
- Overloading indicated by deformation
- For extremely deep or inset bolts
- Top-grade industrial quality for the hardest of continuous use
Technical Specifications
| Net weight [kg] | 0.154 kg |
|---|---|
| Total length [mm] | 235 mm |
| Total width [mm] | 22 mm |
| Total height [mm] | 30 mm |
| Material | Chrome-vanadium steel 31CrV3 |
| Width of head 1 [mm] | 21.6 mm |
| Surface | chrome-plated |
| Width across flats 1 [mm] | 14 |
| Width across flats 2 [mm] | 15 |
| Head height 1 [mm] | 10.6 mm |
| Width across flats [mm] | 14x15 |
| Standard | DIN 838, ISO 3310, ISO 1085, ISO 10104 |
| Width of head 2 [mm] | 23.1 mm |
| Head height 2 [mm] | 11.3 mm |
| Ring profile | UNIT-DRIVE |
| Height of offset 1 | 26.1 mm |
| Ring offset | 5° |
