Product Overview
- Rings deep offset, strong but thin walls
- Satin non-glare finish
- Carefully forged and professionally machined: Ring: thin-walled
- 5° deep offset from shaft, with UD profile for gentle transmission of force
- High bending strength - does not fracture or splinter when overloaded, thus minimising the risk of injury
- Overloading indicated by deformation
- For extremely deep or inset bolts
- Top-grade industrial quality for the hardest of continuous use
Technical Specifications
| Net weight [kg] | 0.258 kg |
|---|---|
| Total length [mm] | 275 mm |
| Total width [mm] | 38 mm |
| Total height [mm] | 33 mm |
| Material | Chrome-vanadium steel 31CrV3 |
| Width of head 1 [mm] | 27.0 mm |
| Surface | chrome-plated |
| Width across flats 1 [mm] | 18 |
| Width across flats 2 [mm] | 19 |
| Head height 1 [mm] | 12.6 mm |
| Width across flats [mm] | 18x19 |
| Standard | DIN 838, ISO 3310, ISO 1085, ISO 10104 |
| Width of head 2 [mm] | 28.8 mm |
| Head height 2 [mm] | 13 mm |
| Ring profile | UNIT-DRIVE |
| Height of offset 1 | 28.6 mm |
| Ring offset | 5° |
