Product Overview
- GEDORE special hardened and tempered steel, drop-forged, oil-hardened and annealed
Technical Specifications
| Net weight [kg] | 0.1 kg |
|---|---|
| Total length [mm] | 126 mm |
| Total width [mm] | 51 mm |
| Total height [mm] | 13 mm |
| Material | Quenched and tempered steel |
| Width of head 1 [mm] | 17.0 mm |
| Surface | chrome-plated |
| Head height 1 [mm] | 16 mm |
| Standard | DIN ISO 5749 |
| Handle design | dip-insulated |
| Handle colour | blue |
| Cutting edge length [mm] | 16 mm |
| Design non-sparking | No |
| Cutting values | Hard wire: 1,6 mm / 14 AWG, Medium hard wire: 2,3 mm / 11 AWG, Soft wire: 3 mm / 9 AWG |
| Hardness of cutting edge | 63 - 65 HRC |
| Joint types | inserted joint |
| Blade shape | with facet |
| Head thickness [mm] T1 | 8.5 mm |
| Thickness of point | 1.0 mm |
| with cutting edge | Yes |
| Hardening process | Induction hardened |
| Bevel | with |
