Product Overview
- Chrom-vanadium-steel
- Operation: Drill a central hole into the broken bolt
- Turn the bolt extractor to the left into this hole until it grips and removes the bolt (penetrating oil may be necessary!)
- Select screw extractors as large as possible
Technical Specifications
| Net weight [kg] | 0.098 kg |
|---|---|
| Total length [mm] | 85 mm |
| Total width [mm] | 15 mm |
| Total height [mm] | 15 mm |
| Material | Chrome-vanadium steel |
| for thread (metric) | M18 - M24 |
| Bore Ø [mm] | 10.3 mm |
| Drive connector square [metric] | 12 mm |
| Hardness [HRC] | 54 HRC |
| for thread (inch) | 3/4" - 1" |
| Diameter range [mm] | 9.4 - 15,0 mm |
