| Net weight [kg] |
2.21 kg |
| Total length [mm] |
462 mm |
| Total width [mm] |
35 mm |
| Total height [mm] |
38 mm |
| Material |
Aluminium alloy |
| Width of head 1 [mm] |
35.0 mm |
| Parts list (Text) |
ALU-extension tube No. 8577-350 |
| Target groups |
Automotive, Industry, Military, Energy, Mechanical engineering, Workshop, Utilities, Service, Agriculture, Oil & Gas |
| Head height 1 [mm] |
30 mm |
| Standard |
DIN 3120 - A 12,5, ISO 1174 |
| Drive square inch |
1/2" |
| Drive connector square [metric] |
12.5 mm |
| Range of application |
Assembly, Series assembly, Production, Maintenance and repair |
| Torque (max.) [Nm] |
120 Nm |
| Drive type/drive |
Single square rigid |
| Torque (min.) [Nm] |
25 Nm |
| Torque (max.) [lbf·ft] |
90 lbf·ft |
| Precision +/- |
+/- 3 % |
| Tightening direction |
Right |
| Torque range (min./max.) [Nm] |
25 Nm - 120 Nm |
| Torque (min.) [lbf·ft] |
18 lbf·ft |
| Torque range (min./max.) [lbf·ft] |
18 lbf·ft - 90 lbf·ft |
| Trigger mechanism |
Short path triggering |
| Test certificate |
DIN EN ISO 6789-02:2017 |
| Graduation [lbf·ft] |
5 lbf·ft |
| Scale division [Nm] |
5 Nm |
| Storage/Content |
in plastic box with aluminium extension tube |
| Torque wrench type |
BR |
| Calibration length |
373 mm |
| Distance housing - square drive |
17.5 mm |
