Product Overview
- For checking or adjusting right-hand torque wrenches and torque screwdrivers, ideal for checking fixed torque wrenches on the line
- Easy to use, electronic test instrument with integrated torsion transducer (DMS)
- With 1/4"
- 3/8"
- 1/2"
- 3/4"
- 1" square adaptor or bit adaptor 1/4" or 3/8" (depending on model)
- High measurement accuracy: +/- 1% tolerance of reading
- 1. peak value detection (first peak / breakpoint detection)
- Autoreset
- Switchable between Nm, lbf·ft and lbf·in
- Serial interface RS232 for PC
- Software for plausibility check on request - Software suite: (Code 3454630)
- Scope of delivery: Electronic torque tester
- RS232 Cable
- Power supply unit with EURO plug (UK
- AUS-adaptor on request)
- 100 - 240 V
- 50 - 60 Hz, max. 500 mA (note type plate)
- 2 socket wrench inserts (size and drive depending on model)
- Adaptor for No. 8612-3150
- Operating instructions
- Packaging
- Test certificate
Technical Specifications
| Net weight [kg] | 26.4 kg |
|---|---|
| Total length [mm] | 320 mm |
| Total width [mm] | 203 mm |
| Total height [mm] | 197 mm |
| Parts list (Text) | Storage box, power supply, connection cable, user manual. Software on request! |
| Adaptor | 1" |
| Drive mount, square [metric] | 40.0 mm |
| Torque (max.) [Nm] | 3150 Nm |
| Torque (min.) [Nm] | 500 Nm |
| Torque (max.) [lbf·ft] | 2323 lbf·ft |
| Measurement accuracy | ± 1 % Toleranz bei allen Ablesewerten, ± 1 Digit |
| Interface | 3.5 mm jack output (RS232) |
| Power source | Kabel |
| Torque range (min./max.) [Nm] | 500 Nm - 3150 Nm |
| Torque (min.) [lbf·ft] | 369 lbf·ft |
| Torque range (min./max.) [lbf·ft] | 369 lbf·ft - 2323 lbf·ft |
| Resolution | 1.0 |
| Befestigung/Montage#153229 | 4x M10 - grade 8.8, with suitable washers and nuts |
