Technical Specifications
| Net weight [kg] | 0.7 kg |
|---|---|
| Total length [mm] | 75 mm |
| Material | Steel |
| Surface | manganese-phosphated |
| Width across flats 1 [mm] | 24 |
| Standard | DIN 3121 - H 25, ISO 1174 |
| Drive mount, square [metric] | 25.0 mm |
| Drive connector square [inch] | 1" |
| Torque (min.) [Nm] | 2400 Nm |
| Backup | Circlip and pin |
| Insertion depth 1 | 26.0 mm |
| Insert-Ø 1 | 54.0 mm |
| Actuation type | machine-operated |
