Name: Gedore 2489708 KL-0039-7533 Sleeve Set, Mercedes Sprinter / VW Crafter
Brand: Gedore
SKU: GED2489708
Price: 353.45 GBP
Availability: InStock

Product Overview

The KL-0039-7533 sleeve set used in conjunction with a GEDORE Automotive press frame of the KL-0039-.. or KL-0043-.. Series and 17 t hydraulic cylinder KL-0040-2500 enables the specified suspension ball joints to be pressed into and pressed out from the lower wishbone quickly and without any trouble. Removal and installation of the suspension ball joints can be carried out in-situ on the vehicle.
Removal and installation of the suspension ball joints can be carried out in-situ on the vehicle.

Technical Specifications

Contents (Qty of pieces)	9
Net weight [kg]	5.1 kg
Parts list (Text)	1x KL-0039-1828-1 - Support sleeve, Ø 60 mm, 1x KL-0039-1823-3 - Spring washer, 1x KL-0039-1823-4 - Cylinder screw, M10 x 120, 1x KL-0039-1823-5 - Spacer tube, 1x KL-0039-1829 - Pressure sleeve, 1x KL-0039-1762 - Pressure sleeve Ø 62 mm, long, 1x KL-
Target groups	Automotive, Construction and commercial vehicles
Suitable for	Suitable for the lower suspension joint on the front axle wishbone, e.g. with Mercedes Sprinter (W901, W902, W903, W904, W906, W907) as well as VW Crafter (2E/2F), VW LT (2D).
Required accessories	Hydraulic drive (17 t):, KL-0040-2500 - Hydraulic cylinder 17 t, KL-0215-35 M25 - Hydraulic pump, KL-0039-1920-1 A - Pull spindle, KL-0041-5041 - Clamping nut with holder, KL-0039-1002 - Adapter, KL-0039-1140 - Press frame, mechanical drive:, KL-0174
Drive type	hydraulic, mechanical
