Product Overview
- One tool that works like a spanner and pliers
- Adjustable, universal tool for bolting
- Perfect for bending, holding, pressing and gripping a wide range of applications
- Play-free positioning with no risk of damaging the edges
- Adjustment of the wrench width via a sliding mechanism and parallel-guided jaws, practically stepless
- Secure locking of the adjustment at the selected wrench width
- Activation of the sliding mechanism from almost any adjustment position
- May be used as a "ratchet spanner" - quick and easy tightening and loosening of hexagonal screws and nuts
- High ratio (>1:10) for high pressing and clamping force against the jaws
- Made of GEDORE special hardened and tempered steel for the highest loads
- Can be used as a powerful vice when on the move
- Optimum ergonomic adjustment of the hand position to the size of the jaw or spanner opening
- Protection jaws available as an option
Technical Specifications
| Net weight [kg] | 0.292 kg |
|---|---|
| Total length [mm] | 190 mm |
| Total width [mm] | 49 mm |
| Total height [mm] | 17 mm |
| Material | Quenched and tempered steel |
| Width of head 1 [mm] | 40.0 mm |
| Surface | chrome-plated |
| Head height 1 [mm] | 25 mm |
| Clamping width [mm] | 42 mm |
| Standard | DIN ISO 5743 |
| Total length [inch] | 7 |
| Handle design | dip-insulated |
| Handle colour | blue |
| Clamping width [inch] | 1.5/8 " |
| Number of setting positions | 18 |
| Design non-sparking | No |
| Jaw length L3 [mm] | 25 mm |
| Joint types | push-through joint |
| Head thickness [mm] T1 | 7.0 mm |
| Size [Inch] | 7 |
| Jaw shape [mm] | flat jaws |
| Thickness of point | 3.0 mm |
