Product Overview
- Voltage 12 V - 1000 V AC/ DC (LED)
- Display levels: 12
- 50
- 230
- 400
- 690
- 1000 V AC/ DC
- Acoustic and optical continuity test up to 100 Ω (buzzer/ yellow LED)
- Rotary field direction (green LED), phase (red LED), polarity (LED)
- Direct display without push button operation (high resistance test)
- Load connection via push-buttons (low-impedance test)
- Deliberate tripping of the RCD
- Non-contact phase tester/cable break detector (yellow LED flashing)
- Vibrating alert in the test handle
- Measuring point illumination
- Protection classification IP65, dust-proof, hose-proof
- Robust housing with rubberized gripping surface
- Over voltage category CAT IV 600 V
Technical Specifications
| Net weight [kg] | 0.425 kg |
|---|---|
| 1000 V insulated | Yes |
| VDE certified | Yes |
| Total length [mm] | 120 mm |
| Material | Plastic |
| Are there any disposal instructions in the operating instructions? | Yes |
| Are there any disposal instructions on the battery? | Yes |
| Disposal instructions on tools | Yes |
| Standard | DIN EN 61243-3, VDE 0682-401 2015 |
| Power source | Batterie |
| Chemical properties | Alkaline primary battery |
| Type of battery | LR03 (AAA) |
| Category at Take e Way | Rub. 2021 Prim.Alkali 0-15g |
| Batteries included in delivery | Yes |
| Number of batteries/rechargeable batteries | 2 |
| Measuring range [Volt] | 12-1000 |
| Voltage range [AC]/DC] | 12 - 1000 V |
| Measuring category | CAT IV 600 V, CAT III 1000 V |
