Product Overview
- Individually tested
- For heavy continuous use
- Good lever action for easy cutting
- For round and flat material
- Extra long blades
- Serrated gripping faces
- High cutting performance with guaranteed 35% less effort
- GEDORE special hardened and tempered steel, drop-forged, oil-hardened and annealed, chrome-plated
Technical Specifications
| Net weight [kg] | 0.365 kg |
|---|---|
| 1000 V insulated | Yes |
| VDE certified | Yes |
| Total length [mm] | 200 mm |
| Material | Quenched and tempered steel |
| Width of head 1 [mm] | 27.0 mm |
| Standard | EN 60900/IEC60900, DIN ISO 5746 |
| Handle design | Dip insulation: double check tool insulation |
| Design non-sparking | No |
| Cutting values | Piano wire: 2,2 mm / 11 AWG, Hard wire: 2 mm / 12 AWG, Medium hard wire: 3,8 mm / 7 AWG, Soft wire: 6 mm / 3 AWG, Cu cable, multi wire cross section: 25 mm², Multi-wire cable Ø: 13 mm |
| Jaw length L3 [mm] | 40 mm |
| Joint types | inserted joint |
| Blade shape | with facet |
| Head thickness [mm] T1 | 12.0 mm |
| Jaw shape [mm] | flat jaws |
| Width of centres W4 [mm] | 6.0 mm |
| Hardening process | Induction hardened |
