Product Overview
Drill stand with cast iron base for vertical drilling using a hand drill. Supplied with drill vice which mounts onto the base to secure the workpiece. Features a preset depth control and stop for drilling depths of up to 60mm. For use with hand drills with a collar diameter of Ø38mm if used with the adaptor bush or Ø43mm if used without. Drill vice features a quick jaw release feature to allow fast and easy adjustment to suit the workpiece.
- Drill stand with cast iron base for vertical drilling using a hand drill.
- Supplied with 65mm drill vice which mounts onto the base to secure the workpiece.
- Features a preset depth control and stop for drilling depths of up to 60mm.
- For use with hand drills with a collar diameter of Ø38mm if used with the adaptor bush or Ø43mm if used without.
- Drill vice features a quick jaw release feature to allow fast and easy adjustment to suit the workpiece.
Technical Specifications
| Nett Weight | 0.00kg |
|---|---|
| Collar Centre to Column | 120mm |
| Maximum Distance Collar to Base | 345mm |
| Column Diameter | Ø25mm |
| Base Size | 155 x 220mm |
| Collar Diameter | Ø43mm (Ø38mm with adaptor bush) |
| Overall Height | 500mm |
| Jaw Width | 65mm |
| Jaw Depth | 25mm |
| Jaw Opening | 70mm |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
