Product Overview
Rugged construction features drop-forged and heat treated pinion gear with totally enclosed mechanisms. Equipped with heavy-duty brake and high quality alloy steel chain. Hooks fitted with safety latches and rotate 360°. Free-chaining feature permits slack in the load chain to be taken up by hand before engaging the ratchet arm. Provides total control on the load position.
- HEAVY-DUTY GEARING - Rugged construction features drop-forged and heat treated pinion gear with totally enclosed mechanisms.
- DURABLE SAFE OPERATION - Equipped with heavy-duty brake and high quality alloy steel chain.
- SAFE AND ANTI-TWIST - Hooks fitted with safety latches and rotate 360°.
- QUICK AND SIMPLE - Free-chaining feature permits slack in the load chain to be taken up by hand before engaging the ratchet arm.
- PRECISE - Provides total control on the load position.
Technical Specifications
| Capacity | 1500kg |
|---|---|
| Chain Falls | 1 |
| Chain Length | 1.5m |
| Head Room | 350mm |
| Hook Aperture | 34mm |
| Lever Length | 363mm |
| Load Chain Diameter | Ø8mm |
| Maximum Hook Capacity Ø | 45mm |
| Nett Weight | 10.1kg |
| Operating Clearance | 104mm |
| Pull on Lever to Lift Full Load | 236N |
| Size (W x D) | 160 x 172mm |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
