Product Overview
Steel drum is reinforced to make the product strong and durable. Rated IP68 weatherproof this winch will withstand any weather conditions. 3-Stage planetary gear train increased pull generated. 2-Brake system with a mechanical cone brake and a permanent motor dynamic brake work together to keep the load stable and protect the user.
- REINFORCED - Steel drum is reinforced to make the product strong and durable.
- WEATHERPROOF - Rated IP68 this winch will withstand any weather conditions.
- 3-STAGE PLANETARY GEARS - Increased pull generated by the gear train.
- 2-BRAKE SYSTEM - Mechanical cone brake and a permanent motor dynamic brake work together to keep the load stable and protect the user.
- WIRE LENGTH - 18m.
- MOTOR - Permanent magnet motor 12V - 1.6HP/1.2KW.
- MAXIMUM WEIGHT - 450kg(1000lbs).
Technical Specifications
| Current Draw | 12V Full Load - 75A |
|---|---|
| Gear Ratio | 140:1 |
| Line Pull* | 454kg 1000lbs |
| Line Speed* | Full Load - 3.8m/min |
| Motor Power | 12V - 1200W |
| Nett Weight | 11kg |
| Rated Capacity | 454kg 1000lbs |
| Min. Breaking Rope Force | 4500lbs (2040kg) |
| Max. Rope Diameter | Ø5.4mm |
| Max. No. of Rope Winding Layers | 4 (Always Keep Working on First Layer) |
| Wire Rope Diameter | Ø4.8mm |
| Wire Rope Length | 18.3m |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
