Product Overview
Multi process IGBT inverter Gas/Gasless MIG/TIG/MMA welder suitable for professional fabricators and workshops, as well as mechanics and technicians. Equipped with a portable wire feeder enabling access into high or tight spaces that would otherwise be difficult to reach. Maximum output of 500A making it ideal for welding a large variety of metals including steel, stainless steel up to 20mm. 2T/4T torch trigger function allowing greater precision during longer welds. Features short circuit, over-heating and over-current protection. Supplied with 2m power cable, 2m earth clamp, 3m Euro non-live MIG torch and 2m Electrode holder. Wire capacity of 5-15kg with a diameter of 0.6mm to 1.6mm. Electrode capacity from 1.6mm to 5mm. Duty Cycle: MIG 60% @ 500A, MMA 60% @ 500A, TIG 60% @ 500A. POWERMIG500Wi is also supplied with a water cooler to prolong duty cycle and efficiency.
- MULTI PROCESS INVERTER WELDER - Multi process IGBT inverter Gas/Gasless MIG/TIG/MMA welder suitable for professional fabricators and workshops, as well as mechanics and technicians.
- PORTABLE WIRE FEEDER – Equipped with a portable wire feeder enabling access into high or tight spaces that would otherwise be difficult to reach.
- 500A MAX OUTPUT - Maximum output of 500A making it ideal for welding a large variety of metals including steel, stainless steel up to 20mm.
- 2T/4T TRIGGER FUNCTION - 2T/4T Torch trigger function allowing greater precision during longer welds.
- SAFETY FEATURES INCLUDE - Features short circuit, over-heating and over-current protection.
- ACCESSORIES INCLUDED - Supplied with 2m power cable, 2m earth clamp, 3m Euro non-live MIG torch and 2m Electrode holder.
- WIRE CAPACITY - Wire capacity of 5-15kg with a diameter of 0.6mm to 1.6mm.
- ELECTRODE CAPACITY - Electrode capacity from 1.6mm to 5mm.
- 3 YEAR GUARANTEE*.
Technical Specifications
| Nett Weight | 76.4kg |
|---|---|
| Welding Current | 30-500A |
| Wire Capacity | 5-15kg |
| Electrode Capacity | 1.6-5mm |
| Duty Cycle MIG | 60% @500A 100% @ 388A |
| Duty Cycle MMA | 60% @ 500A 100% @ 388A |
| Duty Cycle TIG | 60% @ 500A 100% @ 388A |
| Gas Type | CO2, Argon, CO2/Argon Mix |
| Mig Torch (inc) | 3m Euro Non-Live Torch |
| Supply | 400V 3ph |
| Power Supply Cable Length | 2m |
| Weight | 42.5kg |
| IP Rating | IP21S |
| Absorbed Power | 19.04kW |
| Input Current | 39.5A (MMA), 40A (MIG) |
| Output Voltage | 50A/22V to 500A/40V (MMA), 30A/15.5V to 500A/39V (MIG) |
| No Load Voltage | 85V (MMA), 85V (MIG) |
| Efficeincy | 0.8 |
