Product Overview
Aluminium cylinder head with cast iron cylinder gives added resistance to wear. Suitable for on site applications or anywhere that requires 110V. Pump head directly coupled to heavy-duty induction motor for reliable and smooth operation. Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures. Copper wound motor provides longer lasting performance.
- ALUMINIUM CYLINDER HEAD AND CAST IRON CYLINDER - Gives added resistance to wear for improved product life.
- 110V - Suitable for on site applications or anywhere that does not have a 230V supply.
- TWIN GAUGES – One displays the tank pressure and the other displays the working pressures.
- COPPER WOUND MOTOR - Provides longer lasting performance.
- FULLY AUTOMATIC PRESSURE CUT-OUT SWITCH – Cuts off the motor automatically when the maximum pressure is reached.
Technical Specifications
| Air Displacement cfm(L/min) | 6.3(178) |
|---|---|
| Maximum Free Air Delivery cfm(L/min) | 4.6(130) |
| Maximum Pressure | 116psi(8bar) |
| Minimum Rated Supply | 16A |
| Motor Output | 2hp |
| Nett Weight | 29kg |
| Noise Level | 95dB(A) |
| Oil Capacity | 0.27L |
| Outlet | Quick Release Coupling |
| Phase | 1ph |
| Receiver Capacity | 50L |
| Size (W x D x H) | 650 x 390 x 669mm |
| Supply | 110V/16A |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
