Product Overview
Folds for easy storage, freeing valuable workshop space when not in use. Six heavy-duty castor wheels. Pump access from the side for safe handling of heavy loads. Delivered in knock-down form, some self-assembly required. This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
- SPACE SAVING - Folds for easy storage, freeing valuable workshop space when not in use.
- EASY MANOEUVRABILITY - Six heavy-duty castor wheels.
- SIMPLE ACCESS - Pump access from the side for safe handling of heavy loads.
- Delivered in knock-down form for reduced freight cost.
- This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Technical Specifications
| Height Jib Down | 1405mm |
|---|---|
| Height Legs Folded | 1440mm |
| Height of Frame | 185mm |
| Length of Jib Position 1 | 830mm |
| Length of Jib Position 2 | 950mm |
| Length of Jib Position 3 | 1070mm |
| Length of Jib Position 4 | 1190mm |
| Length | 1620mm |
| Lifting Capacity in Position 1 | 1000kg |
| Lifting Capacity in Position 2 | 750kg |
| Lifting Capacity in Position 3 | 500kg |
| Lifting Capacity in Position 4 | 250kg |
| Max. Lift Ht at Jib Position 1 | 1820mm |
| Max. Lift Ht at Jib Position 2 | 1935mm |
| Max. Lift Ht at Jib Position 3 | 2030mm |
| Max. Lift Ht at Jib Position 4 | 2150mm |
| Nett Weight | 67kg |
| Rear Width | 700mm |
| Width Front Frame | 920mm |
| Width Inside Front Frame | 780mm |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
