Product Overview
Fan-cooled DC power supply for TIG and arc welding applications. Outer case manufactured from pressed steel with a powder coated finish for extra corrosion resistance. Portability allows the welder to be taken to the job at hand making it ideal for the mobile technician. Features quick release switch on the torch for control of gas, saving on consumption. Features hot start, anti-stick, forced air cooling, thermal cut-out protection. Suitable for arc welding using the lift start method. Supplied with MMA/TIG Accessories. Optional MMA Electrode Holder: Model No. MMA01.
- Fan-cooled DC power supply for TIG and arc welding applications.
- Outer case manufactured from pressed steel with a powder coated finish for extra corrosion resistance.
- Portability allows the welder to be taken to the job at hand making it ideal for the mobile technician.
- Features quick release switch on the torch for control of gas, saving on consumption.
- Features hot start, anti-stick, forced air cooling, thermal cut-out protection.
- Suitable for arc welding using the lift start method.
- Supplied with MMA/TIG Accessories.
- Duty Cycle: 20% @ 130A, 60% @ 75A, 100% @ 60A.
- Weight: 4.7kg.
- Optional MMA Electrode Holder: MMA01.
Technical Specifications
| Nett Weight | 7.02kg |
|---|---|
| Power Output | 20-130A |
| Duty Cycle | 20% @ 130A, 60% @ 75A, 100% @ 60A |
| Electrode Capacity | Ø1.6-3.2mm |
| Absorbed Power | 4.25kW |
| Supply | 230V* |
| Protection | IP21S |
| Weight | 7.02kg |
| Accessories | Yes |
| Electrode Holder (Included) | Yes |
| TIG Welding Torch (Included) | Yes |
| Note | *To achieve maximum power a 16A supply may be required. |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
