Product Overview
High precision multimeter. Conforms to EN 61010-1 CATIII 600V safety requirements for electrical equipment for measurement, control and laboratory use. Double moulded housing with soft grip case and large display for ease of use. Probe and lead storage. Integral upright stand for use on the workbench. Supplied in zipped pouch with carry strap. Measures: • AC and DC Voltage • DC Current • Resistance • Diode Test • Audible Continuity
- High precision multimeter.
- Conforms to EN 61010-1 CATIII 600V safety requirements for electrical equipment for measurement, control and laboratory use.
- Double moulded housing with soft grip case and large display for ease of use.
- Probe and lead storage.
- Integral upright stand for use on the workbench.
- Supplied in zipped pouch with carry strap.
Technical Specifications
| Nett Weight | 260g |
|---|---|
| AC Voltage (Accuracy) | 200V, 600V (±1.2%) |
| DC Voltage (Accuracy) | 0-200mV, 2000mV, 20V (±0.5%), 200V, 600V (±0.8%) |
| AC Current (Accuracy) | No |
| DC Current (Accuracy) | 0-2000µA, 20mA (±1%), 200mA (±1.2%), 10A (±2%) |
| Resistance (Accuracy) | 0-200Ω, 2000Ω, 20kΩ, 200kΩ (±0.8%), 2000kΩ (±1%) |
| Capacitance (Accuracy) | No |
| Temperature (Accuracy) | No |
| Frequency (Accuracy) | No |
| Duty Cycle | No |
| Continuity Audible | Yes |
| Diode Test | Yes |
| Transistor Test | No |
| Hi-Impact Rubber Case | Yes |
| Digits x Height | 3 x 27.5mm |
| Low Battery Indicator | Yes |
| Battery (Supplied) | 1 x 9V |
| Information | Battery Test 1.5V, 9V (±1%) |
| Size (L x W x D) | 150 x 70 x 48mm |
| Weight | 260g |
| Conformity | EN 61010-1 |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
