Product Overview
Self-priming, rotary vane pump with bypass valve. Direct drive 230V motor fitted with overload protector. Volumetric, nutating disc, resettable meter with large 3-digit display. Supplied with Model No. TP109 Automatic Delivery Nozzle and 4m of reinforced 3/4" hose. Unit is suitable for wall, tank or pedestal installation. Flow rate 56L/min.
- Self-priming, rotary vane pump with bypass valve.
- Direct drive 230V motor fitted with overload protector.
- Volumetric, nutating disc, resettable meter with large 3-digit display.
- Supplied with Model No. TP109 Automatic Delivery Nozzle and 4m of reinforced 3/4" hose.
- Unit is suitable for wall, tank or pedestal installation.
- Flow rate 56L/min.
Technical Specifications
| Current | 3A |
|---|---|
| Flow Rate | 56L/min |
| Nett Weight | 19.15kg |
| Power | 350W |
| Pressure | 29psi(2bar) |
| Protection | IP55 |
| Speed | 2900rpm |
| Voltage | 230V |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
