Product Overview
Heavy-duty steel frame construction with integral air motor powering hydraulic pump unit. Adjustable work area with removable tray. Sliding hydraulic ram assembly giving 360mm of lateral travel for off-centre pressing applications. Frame head fitted with ram pressure gauge. Winch assisted press table adjustment. Storage for press pins included in frame (pins not included). Supplied with flat pressing plate/V-blocks. This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
- Heavy-duty steel frame construction with integral air motor powering hydraulic pump unit.
- Adjustable work area with removable tray.
- Sliding hydraulic ram assembly giving 360mm of lateral travel for off-centre pressing applications.
- Frame head fitted with ram pressure gauge.
- Winch assisted press table adjustment.
- Storage for press pins included in frame (pins not included).
- Supplied with flat pressing plate/V-blocks.
- This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
- A forklift must be available at the delivery point to unload this item.
- 5 Year guarantee*.
Technical Specifications
| Air Consumption | 6.5cfm |
|---|---|
| Bench or Floor Mounting | Floor |
| Capacity | 100 Tonne |
| Gauge Included | Yes |
| Lateral Ram Travel | 360mm |
| Maximum Height - Ram to Table | 885mm |
| Minimum Height - Ram to Table | 185mm |
| Nett Weight | 682kg |
| Operating Table Width | 850mm |
| Overall Height | 1938mm |
| Ram Diameter | Ø179mm |
| Ram Stroke | 300mm |
| Table Aperture | 324mm |
| Type | Air/Hydraulic |
| Working Table Depth | 364mm |
| Working Table Width | 1090mm |
Warranty Information
5 years-year guarantee (parts & labour), in addition to your statutory rights.
