Product Overview
- Tried and tested, strong design for removing discs, wheels, ball bearings etc.
- The wide or narrow hook ends, which can be used on both sides, press themselves automatically when loaded
- The wide leg ends of the puller 1.10/2
- /3
- /4 and /5 possess 8 mm slots, so that pulleys or gears may also be pulled off using 8 mm bolts
Technical Specifications
| Usable clamping reach [mm] | 80 mm |
|---|---|
| Spindle thread size | M 14x1,5 x 125 |
| Width of hooked foot [mm] | 17 mm |
| Usable depth of hooked foot d2 [mm] | 7 mm |
| Thickness of hooked foot at tip | 2.0 mm |
| Width across flats [mm] | 17 mm |
| Tractive force (max.) [t] | 2 |
| Number of arms | 2 |
| Net weight [kg] | 0.67 kg |
| Can be retrofitted with hydraulic spindle | No |
| Clamping width (max.) external pulling [mm] | 90 mm |
| Width of hooked foot | 10 mm |
| Hydraulic spindle optional | - |
