Product Overview
- Very strong
- Especially suitable for industry and for heavy agricultural and construction machinery
- The legs grip automatically
- Can be retrofitted with hydraulic spindle
- Can be used as 2- and 3-arm puller
Technical Specifications
| Usable clamping reach [mm] | 420 mm |
|---|---|
| Spindle thread size | G 1 x 500 |
| Width of hooked foot [mm] | 32 mm |
| Usable depth of hooked foot d2 [mm] | 22 mm |
| Thickness of hooked foot at tip | 3.0 mm |
| Width across flats [mm] | 36 mm |
| Tractive force (max.) [t] | 12 |
| Number of arms | 3 |
| Net weight [kg] | 12.67 kg |
| Can be retrofitted with hydraulic spindle | Yes |
| automatic pressing | Yes |
| Clamping width (max.) external pulling [mm] | 450 mm |
| Hydraulic spindle optional | 1.06/HSP3 |
