Product Overview
- Suitable for removing large ball bearings and bearing outer races
- Operation: By turning the nut, the puller jaws are spread. The newly developed spreading system is simple, stepless and time-saving. The sharp-edged profiles of the puller jaws are set flush under the bearing during spreading
- Both internal extractors can be used with the slide hammer 1.35/3
- If slide hammer No. 1.35/3 is used, the adaptor No. 135/325-I M16x1.5 G 1/2" (Code 1123750) must be ordered as well
Technical Specifications
| Usable clamping reach [mm] | 187 mm |
|---|---|
| Width of hooked foot [mm] | 33 mm |
| Usable depth of hooked foot d2 [mm] | 5 mm |
| Thickness of hooked foot at tip | 6.0 mm |
| Width across flats [mm] | 36 mm |
| Net weight [kg] | 2.312 kg |
| Total length [mm] | 230 mm |
| Total height [mm] | 269 mm |
| Spread range | 60-160 |
| Connecting thread | G 1/2" |
| Support | 1.36/4 1.35/3 |
| Width of head 1 [mm] | 70.0 mm |
| Effective effective hook length [mm] | 213 mm |
| Usable length | 192 mm |
