Product Overview
- With flat heads
- Satin non-glare finish
- Jaw: ground precisely to exact nominal size for optimum contact areas
- Secure grip thanks to slim profile shaft
- Overloading indicated by deformation
- Top-grade industrial quality for the hardest of continuous use
Technical Specifications
| Net weight [kg] | 0.33 kg |
|---|---|
| Total length [mm] | 264 mm |
| Total width [mm] | 55 mm |
| Total height [mm] | 8 mm |
| Material | Chrome-vanadium steel 31CrV3 |
| Width of head 1 [mm] | 53.5 mm |
| Width across flats 1 [mm] | 24 |
| Width across flats 2 [mm] | 26 |
| Head height 1 [mm] | 8 mm |
| Width across flats [mm] | 24x26 |
| Standard | not standardised |
| Width of head 2 [mm] | 56.5 mm |
| not standardised | * |
| Mouth position 1 | 15° |
