Product Overview
- Carefully forged and professionally machined
- Slim jaw and jaw walls make this spanner lighter overall
- Overloading indicated by deformation
- Secure grip thanks to hollow shaft - very ergonomic and handy
- Glare-free look due to matt chrome
- High industrial quality for heavy continuous stress
Technical Specifications
| Net weight [kg] | 0.01 kg |
|---|---|
| Total length [mm] | 85 mm |
| Total width [mm] | 12 mm |
| Total height [mm] | 6 mm |
| Material | Chrome-vanadium steel 31CrV3 |
| Width of head 1 [mm] | 7.7 mm |
| Surface | chrome-plated |
| Head height 1 [mm] | 3.2 mm |
| Standard | similar to DIN 3113 - form A, ISO 3318, ISO 7738 |
| Width across flats 1 [AF] | 3/16" |
| Width of head 2 [mm] | 11.8 mm |
| Head height 2 [mm] | 3.2 mm |
| Ring profile | hexagonal |
| Mouth position 1 | 15° |
| Ring angle | 15° |
