Technical Specifications
| Net weight [kg] | 1.42 kg |
|---|---|
| Total length [mm] | 100 mm |
| Material | Steel |
| Surface | blued |
| Width across flats 1 [mm] | 41 |
| Standard | DIN 3121 - H 25, ISO 1174 |
| Drive mount, square [metric] | 25.0 mm |
| Drive connector square [inch] | 1" |
| Backup | Circlip and pin |
| Working length | 100.0 mm |
| Insert-Ø 1 | 63.0 mm |
| Insert-Ø 2 | 54.0 mm |
| Operating depth | 22.0 mm |
| Actuation type | machine-operated |
