Technical Specifications
| Net weight [kg] | 0.347 kg |
|---|---|
| Total length [mm] | 54 mm |
| Material | Steel |
| Surface | blued |
| Standard | DIN 3121 - H 20, ISO 1174 |
| Drive mount, square [metric] | 20.0 mm |
| Drive connector square [inch] | 3/4" |
| Backup | Circlip and pin |
| Width across flats 1 [AF] | 1.1/16" |
| Working length | 54.0 mm |
| Insert-Ø 1 | 43.0 mm |
| Insert-Ø 2 | 44.0 mm |
| Operating depth | 16.0 mm |
| Actuation type | machine-operated |
