Product Overview
- From SW 95 mm use No. KB 6470 and No. KB 6475
- * not standardised
Technical Specifications
| Net weight [kg] | 5.46 kg |
|---|---|
| Total length [mm] | 110 mm |
| Material | Steel |
| Surface | blued |
| Width across flats 1 [mm] | 90 |
| Standard | DIN 3129, ISO 2725-2, DIN 3121 - H 40, ISO 1174 |
| Drive mount, square [metric] | 40.0 mm |
| Drive connector square [inch] | 1.1/2" |
| Backup | Circlip and pin |
| Working length | 110.0 mm |
| Insert-Ø 1 | 130.0 mm |
| Insert-Ø 2 | 86.0 mm |
| Operating depth | 55.0 mm |
| Actuation type | machine-operated |
