Name: Gedore 2372290 KL-0040-860 Wheel Bearing Tool Set, Ford Transit
Brand: Gedore
SKU: GED2372290
Price: 243.15 GBP
Availability: InStock

Product Overview

The wheel bearing tool set enables quick and professional removal of the bolted wheel bearing unit with wheel hub and brake disc on the front axle, as well as subsequent removal and insertion of the wheel hub on the wheel bearing unit.
For example, this is required when replacing the wheel bearing and brake discs, as these are located behind the wheel hub.
All work can be carried out directly on the vehicle within a few minutes.
A time-consuming removal and installation of the wheel bearing housing as well as a resulting wheel alignment is not necessary.

Technical Specifications

Contents (Qty of pieces)	13
Net weight [kg]	4.6 kg
Parts list (Text)	1x KL-0040-8601 - Pressure disc Ø 77 mm, 1x KL-0040-8602 - Pressure disc Ø 68 mm, 1x KL-0040-8501 A - Pressure ring, 5x KL-0039-1823-4 - Cylinder screw M10 x 120, 5x KL-0040-8503 - Dorn
Target groups	Automotive, Construction and commercial vehicles
Suitable for	Fits with the front axle on Ford Transit/Tourneo (2000-2006 / 2006-2014 / 2014 onwards) with front and all-wheel drive and a hole circle diameter of 97.5 mm and 111 mm of the brake disc fastening screws.
Required accessories	Hydraulic drive (28 t):, KL-0040-2800 - Hydraulic cylinder 28 t, KL-0215-35 M28 - Hydraulic pump, KL-0040-2812-1 - Pull / thrust spindle M24x590, KL-0040-2812-2 - Clamping nut hydraulic drive (17 t):, KL-0040-2500 - Hydraulic cylinder 17 t, KL-0215-3
Wheel stud circles	97.5 mm
Drive type	hydraulic
Load (max.) [t]	28 t
Bolt circle diameter 2 [mm]	111 mm
