Product Overview
- Flat ring ratchet with UD-profile, fine-toothed
- With lowered change-over lever for right/left rotation
- For loosening or fast tightening with high torque transfer
- Non-glare look due to matt chrome-plating, locking insert and pawl manganese-phosphated
- GEDORE vanadium steel 31CrV3
- Forged
Technical Specifications
| Net weight [kg] | 0.075 kg |
|---|---|
| Total length [mm] | 66.2 mm |
| Total width [mm] | 22 mm |
| Total height [mm] | 19 mm |
| Material | Chrome-vanadium steel 31CrV3 |
| Width of head 1 [mm] | 22.0 mm |
| Width across flats 1 [mm] | 10 |
| Head height 1 [mm] | 15.8 mm |
| Return angle | 7 ° |
| Number of teeth | 51 |
| Drive connector rectangular | 9 x 12 |
| Depth gauge [metric] | 40.0 mm |
| Continuous load | 58 Nm |
| Width of head 2 [mm] | 21 mm |
| Head height 2 [mm] | 7.7 mm |
