Product Overview
Heavy-duty steel construction with powder coat paint finish for corrosion resistance. Suitable for use with our lever hoists or chain blocks. Designed for mounting onto an I-beam or RSJ to allow load to be manoeuvred sideways. Geared block trolleys make it easier to move heavy loads along the gantry by using chain rather than manual handling. Incorporates wheel guards to prevent contact with other trolleys mounted on same load bearer.
- PROFESSIONAL USE - Heavy-duty steel construction with powder coat paint finish for corrosion resistance.
- MULTIPLE FUNCTIONS - Suitable for use with our lever hoists or chain blocks.
- EASILY FITTED - Designed for mounting onto an I-beam or RSJ to allow load to be manoeuvred sideways.
- MANOEUVRABILITY - Geared block trolleys make it easier to move heavy loads along the gantry by using chain rather than manual handling.
- SAFETY GUARDS - Incorporates wheel guards to prevent contact with other trolleys mounted on same load bearer.
Technical Specifications
| Nett Weight | 10.8kg |
|---|---|
| Capacity | 1000kg |
| Track Width Adjustable Ramge | 80-146mm |
| Minimum Curve Radius | 900mm |
| A | 213mm |
| B | 151mm |
| C | 115mm |
| D | 72mm |
| E | 107mm |
| Minimum Standard I-Beam Dimensions (D x W x Web) | 180 x 100 x 6mm |
| Maximum Standard I-Beam Dimensions (D x W x Web) | 350 x 150 x 9mm |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
