Product Overview
Aluminium cylinder head with cast iron cylinder gives added resistance to wear. Fitted with fully automatic pressure cut-out switch and air regulator with gauge. Suitable for all general-purpose workshop applications. Vertical tank saves floor space which makes it perfect for small workshops. Fitted with 3-pin plug.
- SPACE SAVING - Vertical tank saves floor space which makes it perfect for small workshops.
- OIL FREE - The benefits of oil free compressors include: Easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
- AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
- ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
- PERFECT FOR WORKSHOPS - Suitable for all general-purpose workshop applications.
Technical Specifications
| Air Displacement cfm(L/min) | 6.04(171) |
|---|---|
| Maximum Free Air Delivery cfm(L/min) | 3.3(93) |
| Maximum Pressure | 116psi(8bar) |
| Minimum Rated Supply | 230V ~ 50Hz |
| Motor Output | 2hp |
| Nett Weight | 22.36kg |
| Noise Level | 86dB(A) |
| Outlet | Quick Release Coupling |
| Phase | 1ph |
| Receiver Capacity | 24L |
| Size (W x D x H) | 490 x 490 x 520mm |
| Speed | 2800rpm |
| Supply | 230V/13A |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
