Product Overview
Heavy-duty 1500W single phase electric motor with over-current sensor to cut power in the event of blade jam. Saw arm fitted with hydraulic damping to prevent it being dropped onto the workpiece and to ensure smooth cutting performance. Coolant system prolongs blade life and makes cutting smoother and more precise.
- POWERFUL - Heavy-duty single phase 1500W motor.
- ADDED SAFETY - Over-current sensor cuts power in the event of blade jamming.
- COOLANT SYSTEM – Prolongs blade life and makes cutting smoother and more precise.
- VARIABLE SPEED – Blade speed can be adjusted to suit material being cut and blade being used.
- STURDY - Precision machined cast iron saw bed.
- HYDRAULIC DAMPING – Saw arm has damping system to prevent arm being dropped, which could damage workpiece as well as the blade, and ensures smooth cutting.
- LARGE CUTTING CAPACITY – Up to 228mm (in height) depending on profile. (See full specification for details).
- NB - This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Technical Specifications
| Nett Weight | 279kg |
|---|---|
| Capacity 90° - Round | Ø228mm |
| Capacity 90° - Square/Rectangular (H x W) | 228 x 335mm |
| Capacity 45° - Round | Ø152mm |
| Capacity 45° - Square/Rectangular (H x W) | 228 x 152mm |
| Blade Size | 3035 x 27 x 0.9mm |
| Blade Speeds | 21, 33, 42 ,59m/min |
| No Load Speed | 1400rpm |
| Motor Power | 1500W |
| Supply | 230V ~ 50Hz |
Warranty Information
1 year-year guarantee (parts & labour), in addition to your statutory rights.
