Product Overview
- Flat pattern
- Thin walled rings
- UD-profile
- * not standardised
Technical Specifications
| Net weight [kg] | 0.136 kg |
|---|---|
| Total length [mm] | 208 mm |
| Total width [mm] | 32 mm |
| Total height [mm] | 9 mm |
| Material | Chrome-vanadium steel 31CrV3 |
| Width of head 1 [mm] | 28.0 mm |
| Surface | chrome-plated |
| Width across flats 1 [mm] | 19 |
| Width across flats 2 [mm] | 22 |
| Head height 1 [mm] | 9.4 mm |
| Width across flats [mm] | 19x22 |
| Standard | ISO 3318, ISO 1085 |
| Width of head 2 [mm] | 32.5 mm |
| Ring profile | UNIT-DRIVE |
