Product Overview
- Straight pattern
- With adjustable reaction square
Technical Specifications
| Net weight [kg] | 0.762 kg |
|---|---|
| Total length [mm] | 230 mm |
| Material | Light metal |
| Outside diameter [mm]. | 75 mm |
| Distance drive square - start reaction arm (min.) | 60 mm |
| Distance drive square - end reaction arm (max) | 159 mm |
| Version reaction arm | L-Form, straight |
| Height of flange ring [mm] | 20 mm |
| Radius of flange ring [mm] | 35.5 mm |
| Height of locking handle [mm] | 30 mm |
| Width reaction arm outer [mm] | 46.5 mm |
| Height square [mm] | 30.8 mm |
