Product Overview
- Designed for the quick, safe and professional removal and replacement of the silentblocs that are found on rear axle trailing arms.
- Removal and installation of the silentblocs can be carried out in situ on the vehicle within just a few minutes, without having to dismount the rear axle trailing arm.
- The special design and shape of the support ring and pressure sleeve ensure that even seized or heavily corroded silentblocs can be pressed out properly and without any trouble.
- The tool also facilitates the accurate positioning of the new silentbloc thus ensuring its correct installation.
Technical Specifications
| Contents (Qty of pieces) | 12 |
|---|---|
| Net weight [kg] | 8 kg |
| Parts list (Text) | 1x KL-0610-151 A - Supplementary kit Ford, Volvo 1x KL-0039-1144 - Base plate 2¼"-14 UNS 2x KL-0215-4004 - Tie rod, 4x KL-0049-3004 - Hexagon nut M18 |
| Target groups | Automotive |
| Suitable for | Suitable for Ford Galaxy (WA6), Mondeo (BA7), S-Max (WA6) und Volvo S60 / V60 (134, 155, 157, Y20), XC 60 (156), S80 (124, 144, AS), V70 / XC70 (135, 136, BW) rear axle trailing arm. |
| Required accessories | Hydraulic drive (17 t): KL-0040-2500 - Hydraulic cylinder 17 t KL-0215-35 M25 - Hydraulic pump KL-0039-1002 - Mounting adapter KL-0039-1930 - Pull spindle hydraulic drive (28 t): KL-0040-2800 - Hydraulic cylinder 28 t KL-0215-35 M28 - Hydraulic pump |
| Drive type | hydraulic, mechanical |
| Load (max.) [t] | 12 t |
| Width, inside (press frame) [mm] | 110 mm |
| Length, inside (press frame) [mm] | 245.5 mm |
