Technical Specifications
| Net weight [kg] | 0.68 kg |
|---|---|
| Material | Chrome-molybdenum steel |
| Surface | phosphated |
| Width across flats 1 [mm] | 27 |
| Standard | DIN 3129, ISO 2725-2, DIN 3121 - H 25, ISO 1174 |
| Drive mount, square [metric] | 25.0 mm |
| Drive connector square [inch] | 1" |
| Backup | Circlip and pin |
| Insertion depth 1 | 15.0 mm |
| Working length | 59.0 mm |
| Insert-Ø 1 | 46.2 mm |
| Insert-Ø 2 | 54.0 mm |
| Actuation type | machine-operated |
| Test torque (min.) [Nm] | 3600 Nm |
| Insertion depth 2 | 29.0 mm |
